Why ICF

Insulated concrete forms (ICF) offer numerous benefits for both builders and homeowners alike. From green building to disaster resilience, ICF homes stand a cut above traditionally constructed home. Here, our experts explain exactly why ICF should be your top choice of building material.

icon energy efficiency

ENERGY EFFICIENCY

Walls with a thick concrete core, sandwiched between thick insulated panels of EPS foam, provide extreme strength and durability. This material will last for lifetimes, keeping your home stable, comfortable and energy efficient. ICF forms will reduce the cost of heating and cooling your home by up to 60% compared to a similar conventionally framed home.

icon Peace And Quiet

PEACE & QUIET

ICFs have a high STC rating which means shouting outside the walls cannot be heard. Noisy neighbors, busy streets, trains, planes, and other annoyances stop at the walls – letting you enjoy your home in peace.

icon Strong Walls

SOLID, STRONG WALLS

Monolithic walls are all poured at once and are one solid piece. Combined with the EPS foam insulation and embedded insulated plastic studs, there’s no need for this house to breathe to eliminate moisture and let in dust, dirt and allergens.
icon green

GREEN CONSTRUCTION

ICFs are green products. Once the bead is produced it is expanded using steam in special molds to create the different shapes and sizes of ICF blocks. When installed, filled with concrete, and finished inside and out, the EPS foam will not degrade or decay. It doesn’t compact or lose its insulation value and will keep insulating for hundreds of years.
icon Comfort

COMFORT INDOORS

Insulated concrete walls protect you from heat and cold, noise, pollution, and Mother Nature herself. This keeps what’s outside where it belongs, leaving you comfortable, quiet and secure no matter the threat.
Fire Icon

4 HOUR FIRE RATING

NUDURA ICF walls are flame resistant and provide a four-hour fire rating compared to a 20-minute rating for conventionally framed structures. This factor alone will help reduce your homeowner’s insurance costs as well as giving you and your family peace of mind.
icon Material

LOWEST WASTE PRODUCT

Should say Nudura ICF’s are specially designed with a 1” repeating interlock pattern, so during the ICF construction, the least necessary is cut off.
icon Disaster

DISASTER RESILIENCE

The core of ICF walls is reinforced concrete. This provides extremely strong walls to support almost any concept or design and will withstand winds of more than 250 mph, impacts from debris, and other challenges life may throw at your home.

Why NUDURA

  • Nudura’s high-tech insulated concrete forms revolutionized the building industry, streamlining construction processes. Rocky Mountain ICF proudly offers these industry leading ICF forms.
  • Nudura ICF enhances efficiency for designers and builders, offering superior thermal resistance, even temperatures throughout the structure, and up to 60% annual energy cost savings for owners.
  • Acting as an effective sound barrier, Nudura ICFs dampen unwanted outside noise, providing a quieter indoor environment.
  • ICF walls feature reinforced concrete and fire-retardant EPS, boasting a fire protection rating for up to 4 hours—quadruple a typical wood-frame home.
  • With high impact resistance and engineering for 250 mph winds, Nudura ICFs ensure safety and durability. The embedded roof/truss anchor system offers better wind uplift resistance and lower life cycle costs.

COMPARING vs. WOOD FRAMING

Comfort and Quiet

Nudura

Wood Frames

Comfort and Quiet

Calculated R-Value

Nudura

R-23.59 (RSI 4.16, U-Value 0.24)

Wood Frames

R-11 to R-19 (RSI 1.94 – 3.35, U-Value 0.52 – 0.30)

Comfort and Quiet

Tested R-Value of Wall*

Nudura

R-24.1 (RSI 4.25, U-Value 0.24)

Wood Frames

R-15.2 (RSI 2.68, U-Value 0.37)

Comfort and Quiet

Reduced Heating & Cooling Cost

Nudura

Yes

Wood Frames

No

Comfort and Quiet

Thermal Mass

Nudura

up to 75 lbs/sq.ft. (3.59kPa)

Wood Frames

2 lbs/sq.ft. (0.10kPa)

Comfort and Quiet

Typical Air Leakage

Nudura

1.11 ACH

Wood Frames

3.36 ACH

Comfort and Quiet

Sound Dampening

Nudura

Effective

Wood Frames

Minimum

*ASTM C-1363 testing per ICFMA/UL(CLEB) Laboratories

Comfort and Quiet

Nudura

Wood Frames

Comfort and Quiet

Bearing Capacity Top of Wall

Nudura

41800plf (60192kg/m)*

Wood Frames

5404plf (8041kg/m)**

Comfort and Quiet

Wind Capacity

Nudura

250mph (402kph)

Wood Frames

90mph (145kph)

Comfort and Quiet

Fire Rating

Nudura

4+ Hours*

Wood Frames

45 mins

Comfort and Quiet

Flying Debris Protection

Nudura

Assured

Wood Frames

Minimal

Comfort and Quiet

Defends Against Termites & Pest Intrusion

Nudura

Yes

Wood Frames

No

Comfort and Quiet

Interior Finish Nail Pop

Nudura

No

Wood Frames

Yes

Comfort and Quiet

Wood Split & Warp

Nudura

No

Wood Frames

Yes

Comfort and Quiet

Risk for Mould Growth & Rot

Nudura

None

Wood Frames

High Risk
*As per Nudura’s UL/ULC listings **As per American Wood Council DES230
